PN532 NFC HAT For Raspberry Pi, I2C / SPI / UART
Overview
This is a Raspberry Pi NFC HAT based on PN532 operating in the 13.56MHz frequency range. It supports three communication interfaces: I2C, SPI, and UART.
NFC (Near Field Communication) is a wireless technology allows contactless point-to-point data communication between devices within a short distance of 10 cm. It is widely used in applications such as access control system, smart tickets, meal card, etc.
Based on the popular NFC controller PN532 with multi interface options, this HAT will easily enable NFC function for your Raspberry Pi.
Features

Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards

Onboard PN532 chip, supports various NFC/RFID cards like MIFARE/NTAG2xx, etc.

Three interface options: I2C, SPI, and UART, configured via jumpers and switches

Breakout control pins, for easily connecting with host boards like STM32/Arduino

Comes with development resources and manual (examples for Raspberry Python/C, STM32, Arduino)

Specifications

NFC controller: PN532

Operating voltage: 3.3V/5V

Operating frequency: 13.56MHz

Communication interfaces: I2C, SPI, UART (default)

Default baudrate: 115200 bps

Operating modes:

reader/writer mode supporting ISO/IEC 14443A / MIFARE scheme

reader/writer mode supporting FeliCa scheme

reader/writer mode supporting ISO/IEC 14443B scheme

card operation mode supporting ISO 14443A / MIFARE scheme

card operation mode supporting FeliCa scheme

card operation mode supporting ISO/IEC18092, ECM340 point-to-point

Applications

Contactless payment system

Bluetooth and WiFi devices chaining

Social sharing function like sharing contacts, photos, and videos

Smart phone NFC app

What's on Board Raspberry Pi GPIO connector:

 for connecting with Raspberry Pi

PN532 control pins:

 for connecting with other host boards like STM32

NFC induction coil PN532 chip:

 NFC controller

Power indicator DIP switches:

 for configuring the connection between PN532 and Raspberry Pi (only one of the I2C/SPI/UART can be connected at the same time)

Mode selection :

I0-L, I1-L: enable UART

I0-H, I1-L: enable I2C

I0-L, I1-H: enable SPI

INT0 jumper:

 response signal, connects to Raspberry Pi D16

RSTPDN jumper:

 reset signal, connects to Raspberry Pi D20

Dimensions
Development Resources Wiki :  https://www.waveshare.com/wiki/PN532_NFC_HAT
Package contains
Note: Raspberry Pi is NOT included.

PN532 NFC HAT x1

MIFARE Classic 1K Card x1
